    W75Cu25 Tungsten Copper Alloy Parts As High Voltage Discharge Electrodes 195HB

    Ask Lasest Price
    Brand Name : Sanhui
    Model Number : W75Cu25, W70Cu30, W80Cu20, W90Cu10
    Certification : ISO 9001:2008
    Price : USD 60-100 per kg
    Payment Terms : D/A, D/P, T/T, Western Union
    Supply Ability : 1000 kgs per month
    Delivery Time : 15-20 days
    • Product Details
    • Company Profile

    W75Cu25 Tungsten Copper Alloy Parts As High Voltage Discharge Electrodes 195HB

    W75Cu25 Tungsten Copper Alloy Parts As High Voltage Discharge Electrodes With Hardness 195HB


    Tungsten Copper Alloy types,chemical compositions and main properties:

    GradeDensity: g/cm3Tensile Strength/MpaHardness (HB)Conductivity %IACSMain Applications
    Room Temperature1600℃
    WCu717.3~17.8400~75050~120280≥26Nozzle, gas rudder
    WCu1016.8~17.3400~70060~100260≥27Nozzle, gas rudder
    WCu1516.0~16.5300~600/240≥30component, barium salt electronic cathode
    WCu2015.1~15.5//220≥34Contact, electrode
    WCu3013.7~14.2//175≥42Contact, electrode
    WCu4012.7~13.2//140≥47Contact, electrode
    WCu5011.7~12.2//115≥55Contact, electrode


    Tungsten Copper alloy Properties:
    Tungsten copper alloy is a composite metal of tungsten and copper, which combines many excellent characteristics of tungsten and copper. Among them, tungsten has high melting point (tungsten melting point is 3410 ℃, copper melting point is 1083 ℃) and high density (tungsten density is 19.34g/cm3, copper density is 8.92g/cm3); Copper has excellent electrical and thermal conductivity. Tungsten copper alloy (composition generally ranges from wcu7 to wcu50) has uniform microstructure, high temperature resistance, high strength, arc erosion resistance and high density; With moderate conductivity and thermal conductivity, it is widely used as military high-temperature resistant materials, electrical alloys for high-voltage switches, EDM electrodes and microelectronic materials. As parts and components, tungsten copper alloy is widely used in aerospace, aviation, electronics, electric power, metallurgy, machinery, sports equipment and other industries.

    No arc erosion: With the right mix of materials.




    By choosing the right mixture of tungsten and copper, we are able to influence the product's arc erosion properties. At a tungsten content of 80 %, we achieve the lowest arc erosion rates. Depending on the voltage and current intensity as well as on economic considerations, we can vary the tungsten content between 60 and 90 % to meet the exact needs of your application.




    We also offer tungsten copper alloy rings, plates, spare parts, etc..
